Count’s Kustoms Les Paul Build

Model/Frame: Wishbone Hardtail
Color: Custom Paint by Ryan Evans: "The idea was to emulate the four most popular colors for the Gibson Les Paul; ebony, ivory, sunburst and the gold. The paint accents incorporated throughout were the ivory the ebony that frames out the exterior of the guitar. The mother of pearl on the rear fender is the exact mother of pearl fret inlays for the custom line guitar models. The tank portrait of Les Paul himself was one in a frame of gold leaf filigree to idealize and immortalize Les."
Wheels: Front; 21 x 2.75, Rear; 16 x 3.25, 40 Spoke. Pirelli tires.
Misc: S+S Super E Carburetor Sifton Cam Transmission: 5 spd. with kicker Belt Drive: 2 inch Midwest Branch Dual Plug Heads
Engine: 1979 HD Shovelhead, 80 cubic inch

Builder: Shannon Aikau

Custom Made Parts by Count’s Kustoms:

  • Gas Tank High Mounted
  • Exhaust
  • Top Engine Mount
  • Auxiliary Fuel Tank originally an aluminum oxygen bottle, engraved by Count’s Kustoms
  • License plate frame and tail light- old brake rotor
  • Handle bars with specific state quarters welded as end caps
  • Hand split rocker boxes accented with top hat guitar knobs

Hand Turned Brass: Gabe at After Hours Choppers

  • Air Cleaner
  • Risers
  • Five Different Lights made out of solid brass with marbles as a reflector of light

Engraving of Brass Parts: Lilian Rose ChoppersHand tooled 10 oz. Custom Leather Seat by Duane Ballard

Note: All modifications made in the innovative and inventive fashion of Les himself. Count’s Kustoms used many different custom functional parts.
